Friday, 27 October 2017

Mesin CNC Router (CNC Router Machine) 2

CNC Adalah Kepakaran Kami Kerana Kami Sendiri Yang Membuatnya!
CNC Is Our Expertise Because Of Our Own Making!

Berikut adalah di antara mesin cnc router yang telah kami buat secara 'custom made'. Jika anda juga berminat untuk menempah mesin cnc dengan kami, sila hubungi kami.

email: kurnia.alrizq@gmail.com
hp: 012-5974968  / 012-3647189 (9am - 6pm)
fax: 06-9811581

http://kurnia-alrizq.blogspot.com/2014/11/satu-daerah-satu-industri-sdsi-2014.html


Ditempah Oleh : Syarikat Persendirian (Kelantan)


3 Axis CNC Router Machine

Axis tinggi (high axis) direka untuk membuat kerja-kerja tebal dan besar.

Specification machine by Kurnia Al Rizq

Custom-made CNC Router Machine by Kurnia Al Rizq

Specifications:
* 4 Axis CNC Router Machine
* Machine Platform Size: X:1600mm x Y:2800MM
* Working Area Size: X:1200 X Y:2500mm
* Working Area 'A' Clearance: 450mm
* Watercooled Spindle Motor 1.5kw with inverter.
* Motor: Stepper Motor 660oz.in
* Liner Guide: Linear Guide
* Liner Movement: Ballscrew and rack & pinion.
* Table top: Adjustable table top
* Command: G-Code
* Controller: PC-Based Mach3
* Untuk membuat kerja-kerja kayu, form bersaiz besar.
* Di buat khas bersama 'hot rod' untuk memotong form.


Ditempah Oleh: Syarikat Persendirian (Johor)


3 Axis CNC Router Machine

Ditempah oleh syarikat yang membuat pengiklanan (signboard).


Specifications:
* 3 Axis CNC Router Machine
* Machine Platform size (mm) : L=3000 X W=1700
* Working Area Size (mm): L=2500 X W=1200 X Z=200
* Motor: Stepper Motor
* Linear Motion: Linear Guide
* Driving Movement: Ballscrew & Rack and Pinion
* Surface Top: MDF Board
* Spindle Motor: 2.2kw Watercooled + inverter
* Command: G-Code
* Controller: PC-Based Mach3
* Untuk kerja-kerja memotong acrylic, mdf board, kayu, form (kerja sign).




Ditempah Oleh: Syarikat Persendirian (Selangor)

Mesin CNC Router


Custom-made cnc router by Kurnia Al Rizq



Specifications:
* 3 Axis CNC Router Machine
* Machine Platform size (mm) : L=2200 X W=1600
* Working Area Size (mm): L=1800 X W=1200 X Z=300
* Motor: Stepper Motor
* Linear Motion: Linear Guide
* Driving Movement: Ballscrew & Rack and Pinion
* Surface Top: MDF Board
* Spindle Motor: 2.2kw Watercooled + inverter
* Command: G-Code
* Controller: PC-Based Mach3
* Untuk kerja-kerja memotong pada material acrylic, mdf board, kayu, form dan lain-lain selain dari besi dan aluminum.




Ditempah Oleh: Syarikat Persendirian (Selangor)

CNC Router Machine




Specifications:
* 4 Axis CNC Router Machine
* Machine Platform size (mm) : L=2900 X W=1600
* Working Area Size (mm): L=2500 X W=1200 X Z=500
* Rotary (diameter) : 300mm
* Motor: Stepper Motor
* Linear Motion: Linear Guide
* Driving Movement: Ballscrew & Rack and Pinion
* Surface Top: Moveable Open Gantry Brige Table
* Spindle Motor: 1.5kw Watercooled
* Command: G-Code
* Controller: PC-Based Mach3
* Untuk kerja-kerja memotong pada material acrylic, mdf board, kayu, form dan lain-lain selain dari besi dan aluminum.


Ditempah Oleh: Universiti Tun Hussein Onn (UTHM)

CNC Router Machine - with working area size 600mm x 400mm


Spesifikasi:
* 3 Axis CNC Router Machine
* Machine Plateform Size (mm): L 900 X W 650
* Working Area Size (mm): L 600 X W 400 ±
* Motor Driver: Micro Step
* Motor: 420 oz Stepper Motor – 1.8˚/Step. DC36V/3Amp.
* Linear Motion: Liner Guide
* Driving Movement: Ball Screw
* Surface Top: MDF Board
* Clamp: Screw Clamping
* Spindle Motor: Water Cooled Spindle 1.5kw with Inverter Input 220V 60Hz- Output 400Hz.
* Spindle Speed: MAX 24,000 RPM
* Collet: ER11 - 6MM
* Speacial Fetures: Auto Tools Zero
* Command: G CODE/TAP Files/NC Files.
* Multi Task: 2D /3D. YES – Engraving and Cutting.
* Controller: PC-Base through parallel port.
* Software Enviroment: Window XP - 32 Bits.
* Acceptable Software: MACH3



* please request us for full specification*
